0.6m 10W / 1.2m 18W / 1.5m 24W
1. This product is waterproof, can use for outdoor lighting.
2. High quality inside non-isolated power supply.
3. Use high quality 2835SMD LEDs.
4. Use the high quality aluminum PCB for LED’s better heat dissipation.
5. High-grade PC cover with nice light transmittance (>95%), Transparent PC cover and frosted PC cover are available.
6. 140º beam angle makes the lighting effect better.
7. Ambient temperature: -20℃~40℃, surface temperature: 42℃~45℃.
8. No mercury, lead or other hazardous materials; no radiation, no electromagnetic radiation, no frequency flash, instant startup, no hurting eyes.
Model: SNS-T8P-600-10W
Power Consumption: 10W
Dimension: φ26 x L600mm
LED Type: 60pcs SMD2835
Luminous Flux: 900-1000lm
LED Color: WW, DW, PW
Color Temperature: 3000K, 4000K, 6000K
CRI (Ra): Ra>70 or Ra>80
Input voltage: 95-265V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 140°
Housing material: Plastic
PC Cover: Milky White or Transparent cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8P-1200-18W
Power Consumption: 18W
Dimension: φ26 x L1200mm
LED Type: 120pcs SMD2835
Luminous Flux: 1800-2000lm
LED Color: WW, DW, PW
Color Temperature: 3000K, 4000K, 6000K
CRI (Ra): Ra>70 or Ra>80
Input voltage: 95-265V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 140°
Housing material: Plastic
PC Cover: Milky White or Transparent cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8P-1500-24W
Power Consumption: 24W
Dimension: φ26 x L1500mm
LED Type: 150pcs SMD2835
Luminous Flux: 2200-2400lm
LED Color: WW, DW, PW
Color Temperature: 3000K, 4000K, 6000K
CRI (Ra): Ra>70 or Ra>80
Input voltage: 95-265V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 140°
Housing material: Plastic
PC Cover: Milky White or Transparent cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
1. Fish tank, chicken farms, pig farms, Herbs shed, vegetable shed, Bridges, commercial building edges.
2. Outdoor lighting, Refrigerator or freezer show lighting, Cold storage lighting, Other humid environments lighting, etc.
