0.6m 10W / 0.9m 12W / 1.2m 18W / 1.5m 22W
1. This product has been UL safety certification approval.
2. High quality inside non-isolated power supply.
3. Use high quality 2835SMD LEDs.
4. Use the high quality aluminum PCB for LED’s better heat dissipation.
5. High-grade PC cover with nice light transmittance (>95%), Transparent PC cover and frosted PC cover are available.
6. 270º beam angle makes the lighting effect better.
7. Ambient temperature: -20℃~40℃, surface temperature: 42℃~45℃.
8. No mercury, lead or other hazardous materials; no radiation, no electromagnetic radiation, no frequency flash, instant startup, no hurting eyes.
Model: SNS-T8-60-10WUL
Power Consumption: 10W
Dimension: φ26 x L590mm
LED Type: 60pcs SMD2835
Luminous Flux: 900-1100lm
LED Color: WW, DW, PW
Color Temperature (K): 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 85-277V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Aluminum + PC
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8-90-12WUL
Power Consumption: 12W
Dimension: φ26 x L898mm
LED Type: 92pcs SMD2835
Luminous Flux: 1100-1300lm
LED Color: WW, DW, PW
Color Temperature (K): 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 85-277V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Aluminum + PC
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8-120-18WUL
Power Consumption: 18W
Dimension: φ26 x L1198mm
LED Type: 120pcs SMD2835
Luminous Flux: 1700-1900lm
LED Color: WW, DW, PW
Color Temperature (K): 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 85-277V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Aluminum + PC
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
Model: SNS-T8-150-22WUL
Power Consumption: 22W
Dimension: φ26 x L1498mm
LED Type: 150pcs SMD2835
Luminous Flux: 2100-2300lm
LED Color: WW, DW, PW
Color Temperature (K): 3000K, 4000K, 6000K
CRI: Ra>80
Input voltage: 85-277V AC
Work frequency: 50/60Hz
Power Supply: Non-isolated Power Supply
PF: >0.9
Beam Angle: 270°
Housing material: Aluminum + PC
PC Cover: Milky white cover
Operating Environment: -20°C to 40°C
Storage Environment: -20°C to 60°C
Theoretical Lifespan: 30000H
Warranty: 3 Years
1. Fish tank, chicken farms, pig farms, Herbs shed, vegetable shed, Bridges, commercial building edges.
2. Outdoor lighting, Refrigerator or freezer show lighting, Cold storage lighting, Other humid environments lighting, etc.
